Tekla Drawing
Our Tekla Drawing Course is meticulously designed to cater to users of all experience levels, from beginners to advanced professionals. This comprehensive program delves into every essential aspect of Tekla drawing creation, providing step-by-step guidance on document management, drawing setup, object-level settings, and advanced customization.
With a structured approach to learning, users will develop the confidence and skills to produce accurate, high-quality drawings in Tekla, ensuring their designs meet industry standards.
WHAT’S WAITING FOR YOU INSIDE
To Thrive In Any Project, You Must Build Your Skillset By Learning Potential And Hidden Features Of Tekla Software
Benefits for Beginners
- Foundational Skills: Gain strong understanding of the Tekla interface, essential drawing types, and document management basics.
- Step-by-Step Guidance: Learn through detailed instructions and easy-to-follow lessons that cover each topic thoroughly.
- Avoid Common Pitfalls: Understand typical challenges beginners face in Tekla and how to avoid them for smoother project setup.
- Confidence in Drawing Creation: Develop the skills to create accurate, professionalquality drawings from scratch.
EƯicient Workflow: Discover time-saving techniques that make learning and working in Tekla easier and more organized.
Benefits for Experienced Users
- Advanced Customization: Master object-level settings and filters to achieve precision in complex drawings.
- In-Depth Insights: Explore advanced topics such as GA drawing configurations, multidrawings, and master setup for eƯicient project management.
- Productivity Boost: Learn tips and tricks like view alignment, copying, and linking drawings to streamline your workflow.
- Enhanced Quality: Produce high-standard, professional drawings that meet or exceed industry standards.
- Optimized Project Execution: Apply expert techniques to save time, reduce errors, and improve drawing consistency across projects.
Five Reasons This Course is a Must for Tekla Users
- Simplifies Complex Tools: Makes Tekla’s powerful drawing tools accessible and easy to use for all skill levels.
- Enhances Document Management: Provides essential skills for organizing and maintaining up-to-date, well-managed drawings.
- Customizes Drawing Experience: Teaches advanced settings, filters, and object-level configurations for more accurate and tailored outputs.
- Optimizes Productivity: Introduces eƯicient techniques like view alignment, copying, and linking, saving time on repetitive tasks.
- Ensures Professional Standards: Guides users in creating industry-standard, highquality drawings that elevate project deliverables.
Whether you are starting with Tekla or looking to expand your expertise, this course is designed to be a game-changer. It empowers users to master Tekla's drawing capabilities, enhancing their workflow and ensuring their projects are completed with precision and eƯiciency. Join this journey and transform your Tekla drawing skills to the next level!
A SKILL SET THAT CAN’T BE MATCHED
You may be out-resourced and out-experienced, yet you can still outshine the giants by thinking differently and creating your own “Tekla mastery stack”. Now you’ll use our exact playbook to do the same in your field. No extensive background required, just dedication and an unbeatable desire to excel.
ENJOY TRUE FREEDOM & FLEXIBILITY
Most engineers stick to the basics, not exploring beyond. That’s what happens when you don’t know how to leverage Tekla to its full potential. You’re compared to everyone else and your competitors outpace. Not you. Our course will help you develop skills centered around value, true dream capabilities in engineering.
WHAT’S WAITING FOR YOU INSIDE
To Thrive In Any Project, You Must Build Your Skillset By Learning Potential And Hidden Features Of Tekla Software
Introduction Lessons
- 1. Download Files
Access and download essential files to get started on your Tekla projects seamlessly. Set up your project environment with the correct resources for eƯective drawing creation.
- 2. Open Tekla Model
Open and navigate Tekla models eƯiciently, preparing for smooth drawing processes. Familiarize yourself with the model setup for accurate referencing.
- 3. Drawing Interface
Explore Tekla’s drawing interface to enhance navigation and usability. Learn about key tools and features for a streamlined drawing experience.
Document Manager
L1. Assembly Drawing Layout
- Configure assembly drawing layouts to meet detailed project requirements.
- Customize layout settings to ensure a comprehensive view of assembled components.
L2. Single Part Drawing Layout
- Develop single-part layouts that capture all necessary details for individual parts. Adjust layout elements for clarity and easy fabrication reference.
L3. Precast Drawing Layout Set up layout configurations for precast drawings to highlight specific precast details. Tailor the layout to suit the unique demands of precast structures.
L4. GA Drawing Layout Arrange and customize layouts for General Arrangement (GA) drawings. o Focus on readability and accurate representation of overall structure.
Document Manager
L1. Document Manager
- Understand diƯerent types of documents and drawings Tekla supports.
- Display, hide, rearrange, and sort columns for better organization.
L2. Document Manager
- Edit columns directly within the document manager to customize views.
- Use search criteria and visibility controls to manage selected documents and objects in the model.
L3. Document Manager
- DiƯerentiate between drawing statuses such as up-to-date, out-of-date, obsolete, and issued.
- Manage drawings eƯectively with options for locked, frozen, and ready-for-issue statuses.
L4. Document Manager
- Create and configure groups to organize specific sets of drawings.
- Set conditions, group indexes, and sorting options for streamlined document display.
Drawings
L1. Assembly Drawing Layout
- L1. Drawing Introduction Get an overview of drawing types available in Tekla and their uses. o Familiarize yourself with each drawing type to apply them eƯectively
- L2. Single Part Drawings Create single-part drawings with a focus on individual component details. Ensure accuracy in every part for seamless assembly.
- L3. Assembly Drawings Develop assembly drawings that highlight complete assemblies for fabrication. Capture all required views and information to support the assembly process.
L4. Multi Drawing Create multi-drawings to combine multiple components into one drawing. Save time and improve eƯiciency by grouping relevant parts.
L5. Super Assembly Drawing Produce super assembly drawings that visualize complex, larger assemblies. o Use advanced techniques to ensure all elements are displayed clearly.
Setting Up Filters
L1. Why Default Settings Are Not for Drawings
- Learn why default settings may not be suitable for precise drawings.
- Understand the benefits of creating custom filters to enhance drawing generation.
L2. Create Filters for Various Profiles
- Set up filters tailored to diƯerent profiles such as angles, channels, hollow sections, and rod sections.
- Customize filters for I, T, and plate profiles for targeted drawing organization.
Object Level Settings
- L1. Introduction Understand the impact of object-level settings on drawing customization. Learn how to apply object-level adjustments eƯectively.
- L2. Object Level Settings for GA Drawings Configure object-level settings specifically for GA drawings. Tailor object views and properties to ensure clarity and consistency.
- L3. Save Object Level Settings for DiƯerent GA Drawing Properties Save customized settings for repeated use across diƯerent GA drawings. Increase eƯiciency by storing frequently used object-level setups.
- L4. Object Level Settings at View Level Apply specific settings at the view level to control individual elements. Enhance the precision of your drawings by managing view-level details.
GA Drawing
- L1. Introduction to GA Drawings Learn the purpose and significance of General Arrangement drawings in Tekla. Explore their applications in detailing the entire structure.
- L2. Key Points Before Creating GA Drawing Understand the essential checks and balances before initiating GA drawing creation. o Ensure your setup aligns with project standards for consistent outputs.
- L3. Moving and Aligning Views Learn techniques for moving and aligning views to optimize your drawings. o Improve drawing readability by precisely positioning views.
- L4. Copying and Linking Drawings Save time by copying and linking drawings for quick duplication and edits. Maintain consistency across drawings by using linked references.
- L5. GA Drawing Properties o Set and adjust properties specific to GA drawings for a customized presentation. Define key attributes that make your GA drawings stand out.
- L6. Anchor Bolt Plan Develop detailed anchor bolt plans to support the construction process. Highlight placement and specifications of anchor bolts in GA drawings.
Single Part Drawing Settings
- L1. Plate Configure settings to highlight essential details for plate drawings. o Ensure every plate drawing is precise and ready for fabrication.
- L2. Column Tailor single-part drawing settings specifically for columns. Accurately represent column dimensions and attributes.
- L3. Angle and Channel Set up angle and channel drawing settings for detailed, informative views. Capture every necessary detail to ensure fabrication accuracy.
- L4. View Configuration Adjust view configurations to improve layout and clarity for single-part drawings. Customize each view for optimal detail presentation.
- L5. Master Drawing Setup Establish a master drawing setup to streamline the Single Part drawing creation process. Use standardized settings for consistent outputs across projects.
Assembly Drawings
- L1. Assembly Drawing Object Level Settings Apply object-level settings to customize assembly drawings for accuracy. Control object properties for clear, organized assembly visuals.
- L2. Assembly View Settings for A3 and A1 Sizes Configure assembly views for A3 and A1 paper sizes to fit project requirements. Adapt view properties for diƯerent scales and formats.
- L3. Assembly Drawing Properties Set specific properties for assembly drawings to highlight necessary details. Customize attributes to align with project specifications.
- L4. Assembly Drawing Creation Learn step-by-step assembly drawing creation for eƯicient documentation. Cover the essential processes for assembling components in Tekla.
Single Part Drawing Settings
- L1. Plate Configure settings to highlight essential details for plate drawings. o Ensure every plate drawing is precise and ready for fabrication.
- L2. Column Tailor single-part drawing settings specifically for columns. Accurately represent column dimensions and attributes.
- L3. Angle and Channel Set up angle and channel drawing settings for detailed, informative views. Capture every necessary detail to ensure fabrication accuracy.
- L4. View Configuration Adjust view configurations to improve layout and clarity for single-part drawings. Customize each view for optimal detail presentation.
- L5. Master Drawing Setup Establish a master drawing setup to streamline the Single Part drawing creation process. Use standardized settings for consistent outputs across projects.
Assembly Drawings
- L1. Assembly Drawing Object Level Settings Apply object-level settings to customize assembly drawings for accuracy. Control object properties for clear, organized assembly visuals.
- L2. Assembly View Settings for A3 and A1 Sizes Configure assembly views for A3 and A1 paper sizes to fit project requirements. Adapt view properties for diƯerent scales and formats.
- L3. Assembly Drawing Properties Set specific properties for assembly drawings to highlight necessary details. Customize attributes to align with project specifications.
- L4. Assembly Drawing Creation Learn step-by-step assembly drawing creation for eƯicient documentation. Cover the essential processes for assembling components in Tekla.
Single Part Drawing Settings
- L1. Plate Configure settings to highlight essential details for plate drawings. o Ensure every plate drawing is precise and ready for fabrication.
- L2. Column Tailor single-part drawing settings specifically for columns. Accurately represent column dimensions and attributes.
- L3. Angle and Channel Set up angle and channel drawing settings for detailed, informative views. Capture every necessary detail to ensure fabrication accuracy.
- L4. View Configuration Adjust view configurations to improve layout and clarity for single-part drawings. Customize each view for optimal detail presentation.
- L5. Master Drawing Setup Establish a master drawing setup to streamline the Single Part drawing creation process. Use standardized settings for consistent outputs across projects.
Numbering
1. Numbering Introduction
- Understand the purpose of numbering in Tekla and how it helps organise and identify components within a model.
- Explore the basics of Tekla's numbering system and how it integrates with project workflows.
2. Basic Process Before Numbering
- Learn the essential steps to prepare a model for numbering, such as cleaning and organising components.
- Avoid common errors by ensuring the model is correctly set up before starting the numbering process.
3. Renumber All
- Discover how to renumber all components in a model eƯiciently, ensuring a clean and updated numbering sequence.
- Save time by using Tekla’s automated renumbering features for large models.
4. Reuse Old Numbers
- Learn to reuse existing numbers to maintain continuity across model revisions.
- Minimise errors and confusion by ensuring previously assigned numbers remain consistent.
5. Check Standard Parts
- Identify and manage standard parts in your model to ensure accurate numbering.
- Understand the role of standard parts in optimising the numbering process for repetitive components.
6. Numbering Comparison
- Compare diƯerent numbering sequences to identify inconsistencies and overlaps.
- Use this feature to maintain a clear and logical numbering hierarchy in complex models.
7. New Number Options
- Explore new number options to customise numbering patterns based on project requirements.
- Configure numbering rules that suit unique client or project specifications.
8. Modified Option in Numbering
- Learn how to use the modified option to update numbers for changed components.
- Ensure that any changes in the model are accurately reflected in the numbering sequence.
9. Tips in Numbering
- Discover expert tips to optimise the numbering process and avoid common pitfalls.
- Improve eƯiciency and accuracy with practical techniques for managing large models.
10. Automatic Cloning
- Automate the numbering process by cloning settings for similar components.
- Save time and ensure uniformity in numbering across repetitive structures.
11. Save Preliminary Numbers
- Learn how to save preliminary numbers for components in the early stages of a project.
- Facilitate smoother transitions to final numbering during later phases of the project.
12. Number Series of Selected Objects
- Assign specific number series to selected objects for better categorisation and organisation.
Customise numbering sequences to align with project-specific needs or standards.
Print Drawings
1. Print Drawings
- Learn how to print drawings eƯectively, choosing the right settings for clarity and scale.
- Understand the importance of accurate print outputs in project documentation.
2. DiƯerent Modes in Print Drawings
- Explore various print modes available in Tekla, such as single and batch printing.
- Choose the appropriate mode to streamline the printing process for your project.
3. Line Properties
- Customise line properties to ensure clear and professional drawing prints.
- Adjust line thickness, colour, and styles to meet project or client specifications.
4. Print Drawings Using Multiple Printers
- Discover how to print drawings using multiple printers simultaneously for faster output.
- Manage printer settings to optimise eƯiciency and minimise errors.
5. Create Package
- Learn to package drawings into a single, organised file for easy sharing and archiving.
- Ensure consistency and accuracy by bundling all relevant documents together.
6. Tips and Tricks
- Gain insights into expert techniques to speed up the printing process and improve output quality.
- Avoid common printing errors with practical advice and tested methods.
7. Customise Print File Names
- Automatically generate customised file names for drawings based on predefined templates.
- Maintain organised documentation with clear and meaningful file names.
Tekla Drawing : A Comprehensive Guide To All
Our Tekla Drawing Course is meticulously designed to cater to users of all experience levels, from beginners to advanced professionals. This comprehensive program delves into every essential aspect of Tekla drawing creation, providing step-by-step guidance on document management, drawing setup, object-level settings, and advanced customization.
AU$99 (ONE TIME PAYMENT)
FREQUENTLY ASKED QUESTIONS
Who are these courses for?
Our courses are designed for structural engineers, BIM professionals, steel detailers, and Tekla users of all experience levels. Whether you're a beginner or an advanced user, we have a course tailored for you.
What do I need to start a course?
Basic knowledge of Tekla Structures is recommended for most courses. However, Beginners can enroll in Drawings and seamless connections courses. You will also need access to Tekla software (a license or trial version).
How Long does each course take?
Our courses are self-paced, allowing you to learn at your convenience.
Beyond Basics: 47 Video lessons.
Learning Time:8 to 10 hours.
Seamless Connection: 78 Video lessons.
Learning Time:15 to 20 hours
Comprehensive Drawing Guide: 79 Video lessons.
Learning Time: 15 to 20 hours.
Master Configuration: 24 Video Lessons.
Learning Time:2 to 3 hours.
Tips and Tricks :
50 Video Lessons.
Learning Time: 10 to 12 hours.
Tekla Open API :
Video lessons :
learning Time: 15 to 20 hours.
It varies, depending on your learning speed and practice time.
How are the courses structured?
Each course includes:
Video tutorials explaining concepts step by step.
Hands-on exercises for practical learning.
Quizzes and assessments to reinforce understanding.
What kind of support is available during the course?
We provide multiple support options:
Discussion forums for student interactions.
Monthly live Q&A sessions with experts.
Email support from instructors.
Can I download course materials for offline use?
Yes, PDF guides, templates, and reference materials are available for download. However, video lessons remain online.
How do these courses help in real-world projects?
Our courses teach practical, job-ready skills, helping you:
Create precise Tekla models and drawings.
Optimize workflows with automation tools.
Apply industry-standard techniques for detailing and fabrication.
How long do I have access to the course?
You get lifetime access, including all future updates to the course materials
What if I’m not satisfied with the course?
We offer a 7-day money-back guarantee deducting international transfer fee, if you are not satisfied.
How do I enroll in a course?
Simply sign up on our website, complete the payment, and start learning immediately.
How do I access to the course after enrollment?
You will receive email with credentials to userid and password.
Login url:
Five Reasons Our Courses are Must for Tekla Users
Simplifies Complex Tools
IBim Consulting's training simplifies Tekla's advanced tools, making complex functionalities easy to understand, saving time, and boosting confidence for all users.
Enhances Document Management
Learn efficient document management techniques, including advanced setups and templates, to ensure consistent, accurate, and professional project documentation with IBim Consulting's training.
Customize Your Software
Tailor Tekla to your needs with IBim Consulting's courses, focusing on the customisation of templates, attributes, and workflows for enhanced usability and project alignment.
Optimizes Productivity
Boost productivity with time-saving techniques, automation tools, and efficient workflows taught in IBim Consulting's practical, results-driven Tekla training courses.
Ensures Professional Standards
IBim Consulting's training helps you achieve industry standards, delivering precise designs and documentation, and fostering expertise for career growth and professional recognition.
